Gear cutting processes | Hobbing, Shaping, Spline Milling, Gashing | ||
Gear Types |
|
|
|
Shaping Workpiece Diameter | Max Ø86” |
||
Shaping tooth size | Max 1 D.P. / 25.4 Mod |
||
Shaping Stroke Length | Max 12.6” / 320 mm |
||
Shaping Workpiece Height | Max 55” / 1397 mm |
||
Hobbing Max Workpiece Diameter | Max 78.7” / 2000 mm |
||
Hobbing Tooth Size | Max < 1 D.P./> 25.4 Mod |
||
Gashing Max Workpiece Diameter | Max Internal 94.5” / 2400mm |
Max External 78.7” /2000 mm |
|
Gashing Max Workpiece Height | Max Internal 57.7” / 1460mm |
Max External 129.9” /3300 mm |
|
Gashing Tooth Size | < 1 D.P./> 25.4 Mod | ||
Material pre-processing | All gear blanks and material can be turned/milled in-house before gear cutting. | ||
Workholding | Custom fixturing and chucks designed and built in-house as needed. | ||
Applications |
|
|
|
